Right-Angle RJ45 Jack, 8P8C, Cat5 — Unshielded Through-Hole
The unshielded thermoplastic housing includes a board guide for alignment during assembly, and the tab points up, matching the standard RJ45 keying.
TE 1-406525-2 RJ45 Jack, 8P8C, Cat5, Right-Angle
MPN1-406525-2
Active
TE Connectivity, 1-406525-2, RJ45 modular jack, 8P8C, Cat5, right-angle, through-hole, unshielded, gold 50.0µin contacts, tray.
$3.0500Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Through Hole |
| Connector type | Jack |
| Operating temperature | -40°C~85°C |
| LED color | Does Not Contain LED |
| Contact material | Phosphor Bronze |
| Housing material | Thermoplastic |
| Package | Tray |
| Ratings | Cat5 |
| Features | Board Guide |
| Shielding | Unshielded |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Tab direction | Up |
| Contact finish | Gold |
| Rows | 1 |
| Number of ports | 1 |
| Contact finish thickness | 50.0µin (1.27µm) |
| Number of positions (Contacts) | 8p8c (RJ45, Ethernet) |
