TE Connectivity AMP Connectors 1-480351-2 — Connector Housings

TE 1-480351-2 Commercial MATE-N-LOK Receptacle Housing

MPN1-480351-2
Active

TE Connectivity Commercial MATE-N-LOK receptacle housing, 1-480351-2, 1 position, 1 row, free-hanging (in-line), crimp termination, red nylon housing, detent lock, -55°C to 105°C.

$0.5100Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesCommercial MATE-N-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

1-480351-2 specifications
ParameterValue
SeriesCommercial MATE-N-LOK
TypeMale Pin
MountingFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeDetent Lock
Operating temperature-55°C ~ 105°C
ColorRed
Insulation materialPolyamide (PA), Nylon
NoteContacts Not Included
PackageBulk
Rows1
Contact terminationCrimp
Positions1

Product details

Single-Position Receptacle Housing for the Commercial MATE-N-LOK Series

The TE Connectivity 1-480351-2 is a single-position receptacle housing from the Commercial MATE-N-LOK series, designed as the female half of a wire-to-wire or wire-to-board interconnect. This is a free-hanging (in-line) housing that accepts male pin contacts via crimp termination — the contacts are ordered separately.

Contacts Are Not Included — Order Separately

The housing ships empty. The note on this line is explicit: contacts are not included. You will need to order the matching male pin crimp terminals from the Commercial MATE-N-LOK terminal range separately. The wire gauge, plating, and current rating are determined by the terminal selected, not the housing itself.

Frequently asked questions

What contacts are compatible with 1-480351-2?

The 1-480351-2 accepts male pin crimp terminals from the Commercial MATE-N-LOK series. The specific terminal part number depends on the wire gauge and plating required — the housing itself does not dictate the terminal; select the pin terminal that matches your wire size and current needs.

Does 1-480351-2 come with contacts included?

No. The listing explicitly notes that contacts are not included. The housing ships empty and must be loaded with separately ordered male pin crimp terminals.

Is 1-480351-2 RoHS compliant?

Yes, the 1-480351-2 is ROHS3 compliant.
