TE Connectivity AMPMODU System 50, 1-487544-2, FFC receptacle housing for female contacts, 15 positions, 0.050" (1.27 mm) pitch, single row, detent lock, UL94 V-0, black polyester, -55°C to 105°C, 1.5 A, 100 V, contacts not included.
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Connector type | Housing for Female Contacts |
| Flat flex type | FFC |
| Voltage rating | 100 V |
| Current rating | 1.5 A |
| Operating temperature | -55°C ~ 105°C |
| Housing color | Black |
| Housing material | Polyester |
| Material flammability rating | UL94 V-0 |
| Note | Contacts Not Included |
| Pitch | 0.050\" (1.27mm) |
| Package | Bulk |
| Rows | 1 |
| Locking feature | Detent Lock |
| FFC, FCB thickness | 0.05-0.08mm |
| Positions | 15 |
The 1-487544-2 is a 15-position, single-row FFC receptacle housing from TE Connectivity's AMPMODU System 50 series. It accepts 0.05-0.08 mm thick FFC and mates with the corresponding AMPMODU System 50 header. The 0.050" (1.27 mm) pitch matches standard 1.27 mm FFC cable.
The TE AMPMODU System 50 series uses specific female crimp terminals for 1.27 mm pitch FFC.
The single-row keying prevents mis-mating.
Buyers need immediate pricing to compare and budget for procurement, directly influencing purchase decisions.
Knowing authorized distributors and stock availability is critical for timely sourcing and avoiding production delays.
Brokers and designers must confirm active status to ensure long-term reliability and avoid supply chain risks.
The housing does not include contacts, so specifying correct mating contacts is essential for proper assembly.
When the exact part is unavailable, engineers need validated alternatives to maintain design integrity.
Ensuring compatibility with standard cables prevents fit failures and costly rework.
