TE Connectivity AMP Connectors 1-640512-0

TE 1-640512-0 MR Receptacle Housing, 12 Pos, 4.20mm Pitch

MPN 1-640512-0
Active

TE Connectivity MR (Miniature Rectangular) receptacle housing, 1-640512-0, 12 positions, 4.20mm pitch, 3 rows, panel mount snap-in, crimp termination, latch lock, black PA66 housing.

$3.4800 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesMR (Miniature Rectangular)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-640512-0 specifications
ParameterValue
SeriesMR (Miniature Rectangular)
TypeMale Pin
MountingPanel Mount, Snap-In
Connector typeReceptacle
Fastening typeLatch Lock
Operating temperature-55°C ~ 85°C
ColorBlack
Insulation materialPolyamide (PA), Nylon
NoteContacts Not Included
Pitch0.165\" (4.20mm)
PackageBulk
Row spacing0.165\" (4.20mm)
Rows3
Contact terminationCrimp
Positions12

Product details

The TE Connectivity 1-640512-0 is a 12-position receptacle housing from the MR (Miniature Rectangular) series, built on a 4.20 mm pitch in a 3-row layout. It is a wire-to-board or wire-to-wire interconnect housing that accepts male pin contacts terminated to 20-24 AWG wire via crimp. Typical use is inside industrial control cabinets, automotive interior harnesses, and appliance power distribution where a compact, vibration-resistant connection is required.

A common BOM mistake is ordering just the housing and wondering why the harness won't mate.

Pitch, Positions, and Panel Fit

The snap-in panel mount requires a rectangular cutout in the panel — no screws or brackets.

Mates with TE MR series pin headers — the male pins in the header engage the female contacts you crimp into this housing. The crimp termination uses standard MR series pin contacts (TE part numbers in the 640512 family).

MPN
1-640512-0
