TE 1-747943-6 AMPLIMITE HDE-20 D-Sub Receptacle, 9 Pos, IDC

MPN1-747943-6
Active

TE Connectivity AMPLIMITE HDE-20, 1-747943-6, D-Sub receptacle, 9 positions, 2 rows, IDC termination, gold 30.0µin contacts, 250V, free-hanging, shielded with backshell.

$14.3100Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1-747943-6 datasheet (PDF)
RoHSROHS3 Compliant
SeriesAMPLIMITE HDE-20
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-747943-6 key specifications
ParameterValue
SeriesAMPLIMITE HDE-20
TypeSignal
MountingFree Hanging (In-Line)
Connector typeReceptacle, Female Sockets
Voltage rating250V
Current ratingVaries by Wire Gauge
Wire gauge22-26 AWG
Shell size, connector layout1 (DE, E)
Operating temperature-55°C ~ 105°C
ColorBlack
Contact materialPhosphor Bronze
Shell material, finishSteel, Tin Plated

All specifications

1-747943-6 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
PackageBulk
FeaturesBackshell, Cover, Mounting Hardware, Shielded
TerminationIDC, Discrete Wire
Contact finishGold
Flange featureCable Side, Male Jackscrew (4-40)
Rows2
Positions9
Contact finish thickness30.0µin (0.76µm)

Product details

AMP LIMITE HDE-20, 9-Position D-Sub Receptacle — IDC Termination, Shielded

It uses IDC termination for discrete 22-26 AWG wire, eliminating the need for crimping or soldering in harness builds. The connector features a steel, tin-plated shell with an integrated backshell, cover, mounting hardware, and shielding — ready for EMI-sensitive signal runs. The UL94 V-0 rated housing meets flame-retardancy requirements for enclosed equipment.

IDC Termination for Harness Efficiency

This speeds up multi-conductor harness assembly but limits rework: once terminated, the wire is not easily removed. The free-hanging mounting style suits cable-to-panel or cable-to-cable connections where the female receptacle mates with a male D-sub plug or panel-mount connector.

Shielding and Mounting Hardware

The steel, tin-plated shell provides EMI shielding for the signal lines within the cable assembly. The flange feature is on the cable side, meaning the jackscrew protrudes from the receptacle to engage with the mating connector's female threaded insert.

Frequently asked questions

Is 1-747943-6 a male or female connector?

It is a female receptacle with socket contacts, designed to mate with a male D-sub plug or panel-mount connector.

Does 1-747943-6 include a backshell?

Yes, the features list includes a backshell, cover, mounting hardware, and shielding — all part of the assembly.
