10-Position Micro MATE-N-LOK Plug Housing for Harness Builds
The 3.00mm pitch provides a compact yet serviceable spacing for 20-24 AWG crimp terminals, balancing board real estate with hand-assembly clearance. This is a panel-mount, snap-in housing with a locking ramp — the ramp engages the mating receptacle with an audible click, giving positive retention under vibration without requiring secondary hardware. Contacts are not included in this listing — the housing ships as a shell only, ready for the specified crimp pins.
Position Count vs 12-Position Sibling
The 10-position 1-794615-0 shares the same 3.00mm pitch, dual-row layout, panel-mount snap-in, and locking ramp with its 12-position sibling 1-794615-2. Choose the 10-position when the harness requires exactly 10 circuits; the 12-position variant is the next step up for the same footprint.
