12-position, 5.08 mm pitch, right-angle shrouded header for terminal block systems
The 1-796638-2: This is a 12-position, single-level header from TE's Termi-Blok, Buchanan series, with a 0.200" (5.08mm) pitch and right-angle orientation. Rated 15 A at 300 V, it handles typical industrial control and power distribution loads.
Right-angle solder termination for board-edge mounting
The through-hole solder tails exit at 90° to the pin axis, so the header sits flat against the PCB edge. Contact tail length is 0.138" (3.50mm), which suits standard 1.6 mm thick boards with through-hole solder joints.
