Right-angle shrouded header for terminal block wiring
The 0.200" (5.08mm) pitch and 15 A at 300 V rating place it in the standard industrial power range for panel wiring and distribution blocks. The right-angle orientation (90°) and through-hole solder termination suit it for board-edge mounting where the wire entry is parallel to the PCB.
At 5.08mm pitch, each position occupies a generous 0.200" of board edge — this is a standard spacing for terminal block headers, allowing easy routing of 14-22 AWG wire to the mating plug. The 16 positions fill a header length of about 3.2" (81.28mm) from pin 1 to pin 16, plus the shrouded end walls. Rated 15 A per contact at 300 V, this header handles typical control circuit power and signal loads.
