TE Connectivity AMP Connectors 1-967241-1 — Connector Housings

TE 1-967241-1 Junior Power Timer Receptacle, 6 Pos, 5.00mm

MPN1-967241-1
Active

TE Connectivity Junior Power Timer receptacle housing, 1-967241-1, 6 positions, 2 rows, 5.00mm pitch, 0.236" row spacing, free-hanging 45° angle, crimp termination, black PBT, contacts not included.

$3.3800Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesJunior Power Timer
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-967241-1 specifications
ParameterValue
SeriesJunior Power Timer
TypeFemale Socket
MountingFree Hanging (In-Line), 45° Angle
Connector typeReceptacle
Operating temperature-40°C ~ 85°C
ColorBlack
Insulation materialPolybutylene Terephthalate (PBT), Glass Filled
NoteContacts Not Included
Pitch0.197\" (5.00mm)
PackageBulk
Row spacing0.236\" (6.00mm)
Rows2
Contact terminationCrimp
Positions6

Product details

Harness-side housing for the Junior Power Timer family

The TE Connectivity 1-967241-1 is a 6-position, dual-row receptacle housing from the Junior Power Timer series, designed for free-hanging harness applications with a 45° wire exit angle. The 5.00 mm pitch and 0.236" row spacing give it a compact but serviceable footprint for automotive and industrial wiring where space is tight but the terminals need to carry moderate current.

The 45° wire exit on this housing helps route the harness parallel to the mating board edge, useful in enclosures where a straight pull would interfere with the lid or adjacent components.

Frequently asked questions

What contacts fit the 1-967241-1 housing?

The 1-967241-1 accepts Junior Power Timer female socket contacts, crimp-terminated. Contacts are not included with the housing and must be ordered separately using the matching terminal part number for your wire gauge.

What is the mating part for 1-967241-1?

The mating half is a Junior Power Timer header (male pin) with the same 5.00 mm pitch and dual-row configuration. The header can be a right-angle or vertical PCB mount version, depending on your board layout.
