Ribbon-Cable IDC Plug for 5-Position Harnesses
The TE Connectivity AMPMODU MTE 103946-4 is a 5-position IDC plug designed for mass-termination to 22-26 AWG ribbon cable. The black housing carries a Closed End feature, meaning the far side of the connector is sealed off — no cable passes through, so the termination stops at the last position.
Wiring and Termination — IDC Fit for Production Runs
This plug terminates via IDC (Insulation Displacement Contact), which means the ribbon cable is pressed onto the contacts without stripping or soldering. The wire gauge range of 22-26 AWG covers standard ribbon cable gauges; 24 AWG is well within the window, answering the common fit question. The free-hanging (in-line) mounting style means the plug floats on the cable — no panel or board lock — so strain relief on the cable bundle matters more than on a board-mounted header. The single-row layout with 5 positions keeps the connector narrow, suited for tight spaces inside an enclosure where a full-width IDC connector would not fit.
