The TE Connectivity 103956-5 is a 6-position IDC receptacle from the AMPMODU MTE series. It terminates discrete 22-26 AWG wire directly via insulation displacement, eliminating the need for individual crimp terminals. A latch lock on the housing provides positive retention once mated, making it suitable for harnesses that see moderate vibration in industrial or commercial equipment enclosures.
Termination and Wiring
IDC termination is the fastest way to build a multi-conductor harness — the insulation is pierced as the wire is pressed into the slot, and the contact bites into the conductor. The 103956-5 accepts 22 to 26 AWG discrete wire; stay within that range to get a reliable gas-tight connection. The free-hanging (in-line) mounting means it floats at the end of the cable, not fixed to a panel or board.
Mating and Locking
The latch lock engages with the mating header's locking ramp to hold the pair together under vibration or cable tug. It is a single-row, 6-position female socket receptacle — it mates with the corresponding AMPMODU MTE header (same pitch, same position count). The black housing colour is a visual identifier for the tin-lead variant; other finishes in the series may be natural or different colours.
