It terminates 22-26 AWG ribbon cable via insulation displacement, making it a direct wire-to-board interconnect for legacy harness assemblies. The 0.100" (2.54mm) pitch matches the standard AMPMODU MTE header footprint — a common choice for control and signal wiring in industrial equipment, test fixtures, and panel interfaces where a compact, inline disconnect is needed.
The 0.100" pitch and 2-position count are the first check against your BOM — this receptacle mates with a 2-position AMPMODU MTE header at the same pitch. The IDC termination accepts 22-26 AWG ribbon cable; the closed-end feature prevents the cable from pushing through the housing during insertion, which simplifies harness assembly. The tin-lead contact finish at 100.0µin (2.54µm) thickness is a legacy plating — adequate for the mating cycle life of a typical field-service interconnect, but the RoHS non-compliance means this part is restricted from new designs requiring RoHS conformance.
