TE Connectivity SMA, 1050903-1, Jack, Female Socket, 50 Ohms, 12.4 GHz, RG-188, Free Hanging, Solder, Threaded, 500 Mating Cycles, Bulk.
| Parameter | Value |
|---|---|
| Mounting type | Free Hanging (In-Line) |
| Connector type | Jack, Female Socket |
| Fastening type | Threaded |
| Voltage rating | 250 V |
| Frequency - max | 12.4 GHz |
| Cable group | RG-188 |
| Operating temperature | -65°C ~ 125°C |
| Body material | Stainless Steel |
| Housing color | Silver |
| Dielectric material | Polytetrafluoroethylene (PTFE) |
| Center contact material | Beryllium Copper |
| Package | Bulk |
| Includes | 5 pcs - 1 Connector, 1 Clamp, 1 Collar, 1 Contact, 1 Insulator |
| Impedance | 50 Ohms |
| Mating cycles | 500 |
| Number of ports | 1 |
| Shield termination | Clamp |
| Contact termination | Solder |
| Center contact plating | Gold |
The threaded coupling provides a secure, vibration-resistant mate.
Supplied in bulk, each order unit includes 5 pieces: 1 connector body, 1 clamp, 1 collar, 1 contact, and 1 insulator — everything needed to terminate one RG-188 cable end.
The 1050903-1 is obsolete but can be sourced to order against an RFQ through independent distribution. Contact the storefront with your BOM quantity for a same-day quote — availability and pricing are confirmed at that time.
Yes, the 1050903-1 is designed for RG-188 cable group. The clamp-style shield termination and solder center contact match the cable construction.
SMA jack, female socket, 50 Ohm impedance, 12.4 GHz max frequency, 250 V voltage rating, 500 mating cycles, free-hanging mount with threaded coupling, solder contact termination, gold-plated beryllium copper center contact, PTFE dielectric, stainless steel body, -65°C to 125°C operating range. Designed for RG-188 cable.
