Amphenol L717DB25PST1
MPNL717DB25PST1
Active
CONN D-SUB PLUG 25POS SCREW
$20.89Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesD-ST
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | D-ST |
| Type | Signal |
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug, Male Pins |
| Voltage rating | 300V |
| Current rating | 7.5A |
| Contact form | Machined |
| Wire gauge | 18 AWG |
| Shell size, connector layout | 3 (DB, B) |
| Operating temperature | -55°C ~ 125°C |
| Color | Black |
| Contact material | Brass |
All specifications
| Parameter | Value |
|---|---|
| Dielectric material | Thermoplastic, Glass Filled |
| Shell material, finish | Steel, Tin Plated |
| Material flammability rating | UL94 V-0 |
| Package | Bag |
| Features | Grounding Indents |
| Termination | Screw |
| Contact finish | Gold |
| Flange feature | Housing/Shell (Unthreaded) |
| Rows | 2 |
| Positions | 25 |
| Contact finish thickness | 8.00µin (0.203µm) |
