Backshell for CPC Connectors, Size 13
The TE Connectivity 1546348-2 is a size 13 backshell with cable clamp for the CPC connector family. The 3/4-20 UNEF thread mates directly to the corresponding CPC connector shell, and the 0.453" (11.51 mm) cable opening accepts the cable bundle that passes through the shell.
What Ships in the Box
The package includes six pieces: four cable clamp pieces and two screws. The clamp splits around the cable, and the screws draw the halves together to grip the jacket. No separate cover is needed — the clamp halves themselves form the enclosure around the cable entry.
Mating and Compatibility Check
This backshell is designed for TE CPC connectors with shell size 13 and a 3/4-20 UNEF thread interface. It mates with the corresponding CPC receptacle or plug that carries the same thread. The 90° exit is a space-saving choice when the cable must run along the panel rather than project outward — common in control cabinets and junction boxes where clearance behind the connector is tight.
