Grace Inertia GIC Receptacle Housing, 4 Circuits
It uses a 3.50 mm pitch and a 4.80 mm row spacing, sized for wire-to-board or wire-to-wire harness interconnects where a positive latch holder keeps the mated pair locked against vibration. Typical applications include automotive interior, appliance, and industrial control harnesses where the inertia-lock design prevents accidental unmating.
Termination is crimp-style — the housing accepts the correct GIC tab contacts, which must be ordered separately as noted on the product line.
The 4-circuit 1565087-1 sits alongside the 6-circuit 1-2069882-6 in the same Grace Inertia family. Both are dual-row, free-hanging receptacles with latch holders and crimp termination. The key difference is the pitch: 3.50 mm on the 1565087-1 versus 5.08 mm on the 1-2069882-6. Choose the 1565087-1 when the board footprint or header pitch is 3.50 mm; the 5.08 mm sibling suits applications needing wider creepage or larger-gauge terminals.
