Battery receptacle, 3 positions, 2.00 mm pitch — right-angle SMT
The black thermoplastic housing includes a board guide for alignment during pick-and-place assembly. Gold-plated contacts on copper alloy carry 2 A per circuit at 30 V, suited for low-voltage battery management and power signal paths in portable devices.
Right-angle SMT — board-edge battery connection
This saves z-height in tight enclosures — common in handheld tools, medical monitors, and IoT gateways where the battery slides in from the side. The SMT solder tails reflow alongside other board components, keeping assembly to a single pass.
2 A per circuit — signal-level current, not bus power
Rated 2 A per circuit at 30 V, this connector handles battery management signals — charge status, thermistor sense, cell-balance lines — rather than the main discharge path. The 2 A rating keeps contact temperature rise low inside a sealed device enclosure.
