TE AMPLIMITE HDF-20 1658615-3, D-Sub Plug 15 Pos IDC

MPN1658615-3
Active

TE Connectivity AMPLIMITE HDF-20 series, D-Sub plug, 15 positions, 2 rows, IDC termination for 26-28 AWG ribbon cable, gold-plated phosphor bronze contacts, 1.25A rating, UL94 V-0.

$7.9800Ref. price · indicative, final on quote
1658615-3 datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

1658615-3 Technical Specifications
ParameterValue
SeriesAMPLIMITE HDF-20
GenderSignal
Mounting typeFree Hanging (In-Line)
Connector typePlug, Male Pins
Current rating1.25A
Wire gauge26-28 AWG, Stranded or Solid
Shell size, connector layout2 (DA, A)
Operating temperature-55°C ~ 105°C
ColorBlack
Contact materialPhosphor Bronze
Dielectric materialThermoplastic
Material flammability ratingUL94 V-0
PackageBulk
FeaturesFeed Through
TerminationIDC, Ribbon Cable
Contact finishGold
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions15

Product details

15-Position D-Sub Plug for Ribbon Cable — IDC Termination

It uses gold-plated phosphor bronze contacts rated at 1.25A per circuit — a signal-level rating that keeps the connector in the data and control domain, not power distribution. The 2-row layout in shell size DA (2) mates with standard DB-15 receptacles, so the footprint and panel cutout follow the D-Sub convention.

No stripping or crimping; the termination is simultaneous across all 15 positions, which saves assembly time on multi-conductor cables but requires the ribbon to be aligned to the connector's pitch. The feed-through feature lets signals pass through the connector body, useful for daisy-chaining in a backplane or panel harness.

Operating Range and Flammability

The unthreaded shell flange means panel mounting uses screws and nuts, not a jack-screw lock; the flange simply aligns the connector to the cutout before the hardware goes in.

Frequently asked questions

What wire gauge works with 1658615-3?

The IDC termination accepts 26-28 AWG stranded or solid wire, configured as a ribbon cable. The insulation displacement contacts are sized for that range; wire outside it will not terminate reliably.
