Drawer Connector Housing for Blind-Mate Power Applications
It carries 8 positions arranged as 4 signal contacts plus 4 power contacts across 2 rows, with a blue housing and an integral guide pin for alignment during mating.
Position Layout and Mating Half
The 8-position layout splits into 4 signal and 4 power circuits, letting a single housing carry both a low-current control bus and a higher-current DC rail. The drawer connector style mates with a corresponding panel-mount or board-mount header in the Blindmate series — the guide pin ensures the two halves align before the contacts engage, which is critical when the connector is hidden behind a panel or in a slide-out chassis. Because the housing accepts male pins, the mating half will be a receptacle housing with female terminals.
Procurement Note: Contacts Ordered Separately
The housing colour is blue, which in the Blindmate series typically distinguishes a specific keying or position arrangement from other colour variants. The guide pin is factory-installed on the housing; no additional alignment hardware is needed.
