60-Position Right-Angle Board-to-Board Receptacle
Gold flash on the contact surface provides corrosion resistance for storage and initial mating, while the through-hole solder tails give the mechanical anchor a 60-position right-angle connector needs to withstand insertion and extraction forces.
Board Layout Fit: Pitch, Footprint, and Orientation
The 0.050-inch pitch is the defining footprint dimension — every PCB layout starts with that row-to-row and contact-to-contact spacing. With 60 positions across two rows, the connector body spans roughly 1.5 inches along the board edge, so the keep-out zone must account for the right-angle body projection beyond the PCB edge. The through-hole tails require plated through-holes sized for the solder tail diameter; the board locks add two additional mounting holes at the ends of the connector body.
It is ROHS3 compliant. No official second-source cross-reference is published, so the BOM line ties to this TE order code.
