TE Connectivity AMP Connectors 1742087-1 — Quick-Disconnect Terminals

1742087-1 Faston Female Flag QC Tab 0.187" 18-22 AWG

MPN1742087-1
Active

TE Connectivity Faston female flag quick-connect terminal, order code 1742087-1, 0.187" (4.75mm) tab width, 18-22 AWG, non-insulated, brass contact, crimp termination, free-hanging right-angle mount.

$0.2000Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesFaston
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

1742087-1 specifications
ParameterValue
SeriesFaston
MountingFree Hanging (In-Line), Right Angle
Terminal typeAngled - 90°, Flag
Wire gauge18-22 AWG
Tab width0.187\" (4.75mm)
Contact materialBrass
GenderFemale
PackageTape & Reel (TR) Cut Tape (CT)
InsulationNon-Insulated
TerminationCrimp
Tab thickness0.032\" (0.81mm)
Insulation diameter0.060\" ~ 0.110\" (1.52mm ~ 2.79mm)

Product details

Flag-style QC for tight wire routing

The 1742087-1 is a Faston-series female flag quick-connect terminal accepting 18-22 AWG wire, with a 0.187" (4.75mm) tab width and 0.032" (0.81mm) tab thickness.

Tab width and wire range vs. Utilux peers

The 1742087-1 uses a 0.187" tab, narrower than the 0.250" tab of Utilux peer 1-1627194-4 (15-18 AWG) and the 0.312" tab of Fastin-Faston PIDG peer 1377175-8 (14-16 AWG). Tab thickness is consistent at 0.032" (0.81mm) across the 1742087-1 and 1-1627194-4; the 1377175-8 uses 0.030" (0.76mm). The 1742087-1's 18-22 AWG range suits lighter circuits than either peer.

Frequently asked questions

What compliance documentation does TE Connectivity provide for 1742087-1?

The 1742087-1 is RoHS compliant per the manufacturer's declaration. No UL or IEC listing is cited in the available records.
