TE Connectivity AMP Connectors 176986-2 — Crimp Contacts

176986-2 TE Connectivity 250 Series 1-Pos Female Housing

MPN176986-2
Active

TE Connectivity AMP Connectors 250 series housing, order code 176986-2, 1 position, female receptacle, 0.250" (6.35mm) quick disconnect, free hanging (in-line), black polyamide (PA66) housing, bulk package.

$0.8000Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Series250
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

176986-2 specifications
ParameterValue
Series250
MountingFree Hanging (In-Line)
Terminal typeQuick Connect, Disconnect
Terminal size0.250\" (6.35mm)
ColorBlack
MaterialPolyamide (PA66), Nylon 6/6
NoteContacts Not Included
StyleHousing
GenderFemale, Receptacle
PackageBulk
Positions1
For use with (Related products)0.250\" (6.35mm) Quick Connects

Product details

Single-position housing for 0.250" quick-connect tabs

The 176986-2 is the 1-position female receptacle housing in TE's 250 series, designed for 0.250" (6.35mm) quick-connect tabs. Free hanging (in-line) mounting, black PA66 housing, bulk packaging.

Comparing to the Utilux 1627127 housing

The 176986-2 shares the same 0.250" (6.35mm) tab size and 1-position count with the Utilux series 1-1627127-0, but the 176986-2 is black PA66 versus natural PA6. Both are free-hanging female receptacles for quick-connect terminals — the colour difference aids visual identification on the harness, not electrical fit.

Frequently asked questions

What does the note 'Contacts Not Included' mean for 176986-2?

The housing ships without the mating quick-connect terminal. The 0.250" (6.35mm) tab terminal must be ordered separately to complete the wire termination.

Will 176986-2 drop into a panel specified around 1-1627127-0 without rewiring?

Both housings accept the same 0.250" (6.35mm) quick-connect tab and share the same 1-position, female receptacle form factor. Mechanical interchange is expected, but the colour difference (black vs natural) and material (PA66 vs PA6) should be verified against the assembly drawing.
