6-Position 3.50mm Pitch Terminal Block Header
The 1986717-6 is a 6-position, single-level terminal block header from TE Connectivity AMP Connectors, with a 0.138" (3.50mm) pitch. It is an unshrouded, vertical male pin header designed for through-hole solder termination. Rated at 2 A and 150 V, it suits signal-level interconnection in control cabinets, PLC I/O modules, and sensor interface boards where the terminal block header mates with a pluggable screw-clamp or spring-clamp connector.
Through-Hole Mounting and Solder Termination
The through-hole mounting style with a contact tail length of 0.138" (3.50mm) provides a robust solder joint for the PCB. Compared to the 1-2213934-1, which shares the same series and package, the 1986717-6 is a 6-position variant; the 1-2213934-1 offers a different position count. Both are active bulk-packaged headers with the same pitch and termination.
