TE Connectivity AMP Connectors 2-2198617-5 — D-Sub Backshells & Hoods

TE ADK D-Sub Backshell 25 Pos, 180° Shielded, 2-2198617-5

MPN2-2198617-5
Active

TE Connectivity ADK series two-piece backshell, 25 positions, 180° cable exit, shielded, nickel plating, includes 4-40 mating screws and grommets, RoHS compliant.

$9.9300Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 2-2198617-5 datasheet (PDF)
RoHSRoHS Compliant
SeriesADK
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

2-2198617-5 specifications
ParameterValue
SeriesADK
Cable typeRound
Accessory typeTwo Piece Backshell
Cable exit180°
ColorSilver
MaterialAcrylonitrile Butadiene Styrene (ABS)
Primary materialPlastic
PackageBulk
PlatingNickel
FeaturesMating Screws 4-40
HardwareAssembly Hardware, Grommets, Strain Relief
ShieldingShielded
Positions25
Compatible D-Sub size25pos and HD44pos
Compatible shell sizeB

Product details

D-Sub Backshell for 25-Position Shell Size B

The TE Connectivity 2-2198617-5 is a two-piece plastic backshell from the ADK series, designed to fit standard 25-position D-sub connectors with Shell Size B. The ABS housing includes the assembly hardware — 4-40 mating screws, grommets, and strain relief — so the backshell arrives ready to install without sourcing separate fasteners.

25 vs 37 Positions — Same Shell Size, Different Cable Bundle

The same ADK series includes a 37-position variant, 3-2198617-7, that shares the Shell Size B footprint. The 25-position 2-2198617-5 fits the standard DB-25 cable bundle; the 37-position sibling takes a larger round cable for the extra conductors. Both use the same 4-40 screw hardware and shielded construction — the choice is driven by the D-sub pin count on the harness.

Frequently asked questions

Does 2-2198617-5 include mating screws and grommets?

Yes. The 2-2198617-5 ships with 4-40 mating screws, grommets, and strain relief hardware included — no separate fasteners needed for assembly.

Is 2-2198617-5 compatible with standard 25-pin D-sub connectors?

Yes. The backshell is designed for Shell Size B, which fits standard 25-position D-sub connectors, including both the 25pos and HD44pos shell formats.

What is the cable clamp OD range for 2-2198617-5?

The cable clamp OD range is not listed in the available specifications for this part. The backshell accepts round cable per the 180° cable exit design — confirm the cable diameter with the product drawing before ordering.
