PIDG ring terminal for 16-22 AWG, #5/16 stud
The 2-31895-1 is the #5/16 stud member of TE's PIDG ring terminal line, accepting 16-22 AWG wire with a tin-plated copper contact and a red polyamide insulation sleeve.
TE PIDG 2-31895-1 Ring Terminal, 16-22 AWG, #5/16 Stud
MPN2-31895-1
Active
TE Connectivity AMP Connectors PIDG ring terminal, order code 2-31895-1, 16-22 AWG, #5/16 stud size, circular terminal type, tin-plated copper contact, insulated, serrated termination, free hanging, tape and reel packaging.
$0.6900Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesPIDG
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | PIDG |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Circular |
| Wire gauge | 16-22 AWG |
| Color | Red |
| Contact material | Copper |
| Width - outer edges | 0.469\" (11.91mm) |
| Material - insulation | Polyamide (PA), Nylon |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Serrated Termination |
| Thickness | 0.031\" (0.79mm) |
| Insulation | Insulated |
| Termination | Crimp |
| Stud (Tab size) | 5/16 Stud |
| Contact finish | Tin |
| Length - overall | 1.078\" (27.38mm) |
| Insulation diameter | 0.105\" ~ 0.140\" (2.67mm ~ 3.56mm) |
Product details
Frequently asked questions
How does 2-31895-1 compare to 2-31897-2?
The 2-31895-1 uses a 5/16 stud; the 2-31897-2 uses a 3/8 stud. Both accept 16-22 AWG, have the same 0.031" thickness, red insulation, and tin-plated copper contacts. Select by stud hole size.
