TE Connectivity AMP PIDG spade terminal, order code 2-320861-2, 14-16 AWG, #6 stud size, tin-plated copper contact, insulated blue nylon, serrated crimp, free-hanging in-line mount, bulk package.
| Parameter | Value |
|---|---|
| Series | PIDG |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Flanged |
| Wire gauge | 14-16 AWG |
| Color | Blue |
| Contact material | Copper |
| Width - outer edges | 0.294\" (7.47mm) |
| Material - insulation | Polyamide (PA), Nylon |
| Package | Bulk |
| Features | Serrated Termination |
| Insulation | Insulated |
| Termination | Crimp |
| Parameter | Value |
|---|---|
| Stud (Tab size) | 6 Stud |
| Contact finish | Tin |
| Length - overall | 0.768\" (19.51mm) |
| Insulation diameter | 0.105\" ~ 0.150\" (2.67mm ~ 3.81mm) |
| Length - termination | 0.404\" (10.26mm) |
| Tongue inside opening | 0.145\" (3.68mm) |
| Length - ring center to termination | 0.203\" (5.16mm) |
The 2-320861-2 is a flanged spade terminal from TE's PIDG series, accepting 14-16 AWG wire and terminating to a #6 stud. The tin-plated copper contact and serrated crimp bite through oxide on the conductor for a gas-tight joint. Overall length is 0.768" (19.51 mm); the insulation barrel accepts wire insulation diameters from 0.105" to 0.150" (2.67 mm to 3.81 mm). The blue nylon sleeve is rated for the wire range and colour-coded per industry convention.
TE Connectivity AMP Connectors manufactures the 2-320861-2. Quoted against the BOM quantity; availability confirmed at RFQ.
