TE Connectivity AMP Connectors PIDG spade terminal, order code 2-32562-1, 16-22 AWG, #6 stud, red, insulated, tin-plated copper, serrated crimp, free hanging in-line.
| Parameter | Value |
|---|---|
| Series | PIDG |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Flanged |
| Wire gauge | 16-22 AWG |
| Color | Red |
| Contact material | Copper |
| Width - outer edges | 0.296\" (7.52mm) |
| Material - insulation | Polyamide (PA), Nylon |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Serrated Termination |
| Insulation | Insulated |
| Termination | Crimp |
| Parameter | Value |
|---|---|
| Stud (Tab size) | 6 Stud |
| Contact finish | Tin |
| Length - overall | 0.768\" (19.51mm) |
| Insulation diameter | 0.105\" ~ 0.140\" (2.67mm ~ 3.56mm) |
| Length - termination | 0.404\" (10.26mm) |
| Tongue inside opening | 0.145\" (3.68mm) |
| Length - ring center to termination | 0.203\" (5.16mm) |
The 2-32562-1 is a red insulated PIDG spade terminal from TE Connectivity AMP Connectors, accepting 16-22 AWG wire and terminating to a #6 stud. The flanged tongue has a 0.145" inside opening, and the serrated crimp barrel grips the conductor through the nylon insulation.
Available in Tape & Reel or Cut Tape packaging.
