TE Connectivity AMP Connectors PIDG ring terminal, order code 2-326882-1, 14-16 AWG, #6 stud size, blue insulated, tin-plated copper contact, 0.031" (0.79mm) thickness, serrated crimp termination.
| Parameter | Value |
|---|---|
| Series | PIDG |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Circular |
| Wire gauge | 14-16 AWG |
| Color | Blue |
| Contact material | Copper |
| Width - outer edges | 0.312\" (7.92mm) |
| Material - insulation | Polyamide (PA), Nylon |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Serrated Termination |
| Thickness | 0.031\" (0.79mm) |
| Insulation | Insulated |
| Termination | Crimp |
| Stud (Tab size) | 6 Stud |
| Contact finish | Tin |
| Length - overall | 0.813\" (20.65mm) |
| Insulation diameter | 0.115\" ~ 0.170\" (2.92mm ~ 4.32mm) |
The 2-326882-1: The tin-plated copper contact is 0.031" (0.79mm) thick and the serrated crimp bites through oxide for a gas-tight connection.
The 2-326882-1's #6 stud and 14-16 AWG range place it between the 2-326878-1 (same #6 stud, 16-22 AWG, red) and the 2-320306-1 (#8 stud, 14-16 AWG, blue) — the insulation material, thickness, and serrated termination are shared across the series.
The 2-326882-1 is RoHS Compliant per TE Connectivity AMP Connectors.
