TE Connectivity AMP Connectors 2-521104-2 — Quick-Disconnect Terminals

TE Ultra-Fast 2-521104-2 QC Tab, 0.187"

MPN2-521104-2
Active

TE Connectivity AMP Connectors Ultra-Fast male quick-disconnect tab, order code 2-521104-2, 0.187" (4.75mm) tab width, 0.032" (0.81mm) tab thickness, 18-22 AWG, tin-plated brass, fully insulated, free hanging, crimp termination, red color.

$0.4700Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesUltra-Fast
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

2-521104-2 specifications
ParameterValue
SeriesUltra-Fast
MountingFree Hanging (In-Line)
Terminal typeStandard
Wire gauge18-22 AWG
ColorRed
Tab width0.187\" (4.75mm)
Contact materialBrass
GenderMale
PackageTape & Reel (TR) Cut Tape (CT)
InsulationFully Insulated
TerminationCrimp
Tab thickness0.032\" (0.81mm)
Contact finishTin
Length - overall0.793\" (20.14mm)
Insulation diameter0.135\" (3.43mm)

Product details

Tab dimensions and wire range

The 2-521104-2 is the 0.187" tab-width member of TE's Ultra-Fast quick-disconnect series, a fully insulated male terminal for 18-22 AWG wire. Tab thickness is 0.032" (0.81mm) with tin-plated brass contact material; the insulation barrel accepts a maximum insulation diameter of 0.135" (3.43mm).

Tab thickness variant in the series

Within the 0.187" tab-width Ultra-Fast male terminals, the 2-521104-2 uses a 0.032" tab thickness while the sibling 2-521102-2 uses a thinner 0.020" (0.51mm) tab — the wire range, insulation diameter, and overall length are shared across both.

Frequently asked questions

What compliance documentation is available for 2-521104-2?

The terminal is RoHS Compliant per the manufacturer listing.
