TE Connectivity AMP Connectors 2-84982-1 — FFC / FPC Cable Assemblies

2-84982-1 TE Connectivity FFC FPC Connector 21 Pos 1mm SMT

MPN2-84982-1
Active

TE Connectivity AMP Connectors 2-84982-1, FFC/FPC vertical SMT connector, 21 positions, 1.00 mm pitch, 1 A per contact, tin finish, active production.

$0.9796Ref. price · indicative, final on quote
RoHSROHS3 Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

2-84982-1 specifications
ParameterValue
MountingSurface Mount
Cable end typeStraight
Flat flex typeFFC, FPC
Connector (Contact type)Contacts, Vertical - 1 Sided
Voltage rating125V
Current rating1A
Operating temperature-20°C ~ 85°C
Housing colorBeige
Contact materialPhosphor Bronze
Housing materialPolyamide (PA), Nylon, Glass Filled
Height above board0.220\" (5.59mm)
Pitch0.039\" (1.00mm)
PackageTape & Reel (TR) Cut Tape (CT)
TerminationSolder
Contact finishTin
FFC, FCB thickness0.30mm
Positions21

Product details

21-position vertical SMT FFC/FPC connector

The 2-84982-1 is a 21-position, 1.00 mm pitch FFC/FPC connector from TE Connectivity, designed for vertical surface-mount termination. It accepts 0.30 mm thick FFC and uses a straight cable entry — the contact beam wipes the pad on insertion and the housing holds the cable without a secondary latch.

Tin contacts and 1 A current ceiling

The 1 A per-contact rating is the thermal limit at 85 °C ambient; derate current above that temperature per the derating curve in the product drawing. The 125 V voltage rating covers most low-voltage signal rails.

Frequently asked questions

Where can I buy 2-84982-1 and how do I get a price?

Submit an RFQ for current pricing and lead time — availability is confirmed at quote time.
