TE Connectivity AMP Connectors 281784-4 — Panel-Mount & In-Line Circular

TE 281784-4 HE13/HE14 4-Pin IDC Plug, 0.100" Pitch

MPN281784-4
Active

TE Connectivity HE13/HE14 series, 4-position IDC plug, 0.100" (2.54mm) pitch, 1 row, gold-plated female sockets, free-hanging, 24-26 AWG, detent lock, bulk.

$0.7800Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesHE13/HE14
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

281784-4 specifications
ParameterValue
SeriesHE13/HE14
Wire typeDiscrete
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typePlug
Fastening typeDetent Lock
Wire gauge24-26 AWG
Cable terminationIDC
ColorBlue
Pitch0.100\" (2.54mm)
PackageBulk
Contact finishGold
Rows1
Positions4
Contact finish thickness15.0µin (0.38µm)

Product details

4-Pin IDC Plug for Discrete Wire Harnesses

The TE Connectivity 281784-4 is a 4-position IDC plug from the HE13/HE14 series, designed for mass-termination to discrete 24-26 AWG wire without stripping or crimping. The 0.100" (2.54mm) pitch matches the standard ribbon-cable footprint, making it a direct fit for mating headers on 0.100" centers.

The IDC termination accepts 24-26 AWG discrete wire, and the free-hanging (in-line) mounting style suits harness assemblies where the plug is not board-mounted.

Frequently asked questions

What is the mating connector for 281784-4?

The 281784-4 mates with a matching HE13/HE14 series header on 0.100" (2.54mm) pitch, typically a 4-position pin header with the same detent lock feature.

What wire gauge works with 281784-4?

The IDC termination accepts 24-26 AWG discrete wire.
