Two-Position 5.08mm Pitch Plug for Control Wiring
Rated 15 A at 300 V, the plug handles typical signal and moderate-power circuits without derating concerns in a 40°C ambient. The rising cage clamp termination accepts 12-30 AWG wire with a strip length of 6-7.5mm, and the screw torque is specified at 0.79 Nm (7.0 Lb-In) — a setting that avoids both stripped threads and loose connections under vibration.
RoHS3 compliant, with a UL94 V-0 polyamide housing that meets the flame rating required inside enclosed equipment.
Free-hanging (in-line) plug with 180° wire entry — mates with a 5.08mm pitch pin header, typically a TE Connectivity Buchanan header or equivalent. Side interlocking features allow ganging multiple plugs side-by-side for multi-circuit assemblies; retention latches on the non-wire side hold the mated pair together. Phosphor bronze contacts with tin mating finish provide adequate cycle life for field-service connections in a controlled environment.
