TE Connectivity AMP Connectors 282837-9 — Wire-to-Board Headers

TE Connectivity 282837-9 Buchanan Terminal Block, 9 Position

MPN282837-9
Active

TE Connectivity Buchanan 282837-9, 9 position, 1 level, 5.08mm pitch, 13.5 A, 300 V, through hole, screw - rising cage clamp, green housing.

$3.5300Ref. price · indicative, final on quote
RoHSRoHS non-compliant
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

282837-9 key specifications
ParameterValue
SeriesBuchanan
MountingThrough Hole
Voltage300 V
Current13.5 A
Wire gauge16-28 AWG
Wire terminationScrew - Rising Cage Clamp
ColorGreen
Housing materialPolyamide (PA66), Nylon 6/6
Clamp material - platingBrass - Nickel Plated
Screw material - platingBrass - Nickel Plated
Contact material - platingBrass - Tin Plated
Pitch0.200\" (5.08mm)

All specifications

282837-9 additional specifications
ParameterValue
PackageBulk
FeaturesInterlocking (Side)
Screw threadM3
Torque - screw0.68 Nm (6 Lb-In)
Number of levels1
Mating orientationHorizontal with Board
Positions per level9

Product details

Buchanan 9-Position PCB Terminal Block, 5.08 mm Pitch

The green polyamide (PA66) housing carries the 13.5 A per-circuit rating, and the side interlocking feature lets multiple blocks be ganged into a multi-position assembly without additional hardware.

The rising cage clamp accepts 16-28 AWG solid or stranded wire. The M3 screw is torqued to 0.68 Nm (6 Lb-In) — exceeding that spec risks stripping the brass-nickel screw or deforming the clamp. The clamp and screw are both brass with nickel plating; the contact surface is brass with tin plating, which is standard for a screw-clamp termination and provides adequate corrosion resistance in indoor control cabinets.

Frequently asked questions

Is 282837-9 RoHS compliant?

No — the 282837-9 is listed as RoHS non-compliant. For regulated markets, source a lead-free alternative from the Buchanan series.

What is the pitch of 282837-9?

The pitch is 0.200" (5.08 mm), which is the standard spacing for this Buchanan series and matches the PCB hole pattern for a 9-position block.

What wire gauge can 282837-9 accept?

The rising cage clamp accepts 16-28 AWG solid or stranded wire. The M3 screw torque spec is 0.68 Nm (6 Lb-In).
