TE Connectivity 282842-2 Buchanan Terminal Block, 2 Position

MPN 282842-2
Active

TE Connectivity Buchanan 282842-2 PCB terminal block, 2 positions, 10.00mm pitch, 17.5 A, 600 V, side-entry screw rising cage clamp, through-hole, green housing.

$1.0100 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSRoHS Compliant
IncotermsDAP / DDP Available
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

282842-2 key specifications
ParameterValue
SeriesBuchanan
MountingThrough Hole
Voltage600 V
Current17.5 A
Wire gauge12-30 AWG
Wire terminationScrew - Rising Cage Clamp
ColorGreen
Housing materialPolyamide (PA66), Nylon 6/6
Clamp material - platingBrass - Nickel Plated
Screw material - platingBrass - Nickel Plated
Contact material - platingBrass - Tin Plated
Pitch0.394\" (10.00mm)

All specifications

282842-2 additional specifications
ParameterValue
PackageBulk
FeaturesInterlocking (Side)
Screw threadM3
Torque - screw0.79 Nm (7.0 Lb-In)
Number of levels1
Mating orientationHorizontal with Board
Positions per level2

Product details

Terminal block for PCB power distribution

The 10.00 mm pitch spaces the two positions wide enough to handle 600 V and 17.5 A per circuit without tracking between adjacent terminals — this is a power block, not a signal-level interconnect. The green housing follows the panel convention for ground/earth identification, though the block itself is not limited to that function. The M3 screw is torqued to 0.79 Nm (7.0 Lb-In) to pull the stripped conductor into the brass cage, which is nickel-plated to resist corrosion under the clamping force.

Wire range is 12-30 AWG — the 12 AWG end handles the full 17.5 A without overheating; the 30 AWG end covers signal-level control wiring. The rising cage clamp pulls the conductor into the cage as the screw tightens, which keeps the wire strands contained and prevents cold flow over time. The side-entry orientation (horizontal with board) means the wires run parallel to the PCB surface, useful when vertical clearance above the board is tight. The interlocking side feature lets multiple 282842-2 blocks be ganged together side-by-side for multi-circuit distribution without gaps between housings.
