TE Connectivity AMP Connectors 282852-3

TE Connectivity 282852-3 Buchanan Terminal Block, 3 Pos

MPN 282852-3
Active

TE Connectivity Buchanan 282852-3, PCB terminal block, 3 positions, 10.00mm pitch, 17.5 A, 600 V, through hole, top entry, screw rising cage clamp, green housing.

$1.6100 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSRoHS Compliant
IncotermsDAP / DDP Available
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

282852-3 key specifications
ParameterValue
SeriesBuchanan
MountingThrough Hole
Voltage600 V
Current17.5 A
Wire gauge12-30 AWG
Wire terminationScrew - Rising Cage Clamp
ColorGreen
Housing materialPolyamide (PA66), Nylon 6/6
Clamp material - platingBrass - Nickel Plated
Screw material - platingBrass - Nickel Plated
Contact material - platingBrass - Tin Plated
Pitch0.394\" (10.00mm)

All specifications

282852-3 additional specifications
ParameterValue
PackageBulk
FeaturesInterlocking (Side)
Screw threadM3
Torque - screw0.79 Nm (7.0 Lb-In)
Number of levels1
Mating orientationVertical with Board
Positions per level3

Product details

It uses a screw-driven rising cage clamp to secure stripped wire from 12 to 30 AWG — the clamp pulls the conductor up against a nickel-plated brass contact, giving a gas-tight connection without damaging the wire strands. The 17.5 A per-position rating and 600 V voltage class suit it for industrial control panels, power supplies, and HVAC equipment where a single-level, vertical-wire block is needed. The green polyamide housing is a visual signature of the Buchanan family, making it easy to spot on a crowded board.

Wiring and Installation Details

The rising cage clamp accepts solid or stranded wire — strip length is not listed in the spec, but the M3 screw torque is specified at 0.79 Nm (7.0 Lb-In). Over-torquing can strip the nylon threads; under-torquing leaves the clamp loose. The side interlocking feature lets you snap multiple 282852-3 blocks together to build a multi-position strip without extra brackets — useful when your circuit count exceeds three and you want a clean, ganged assembly on a single PCB footprint.
