TE Connectivity AMP Connectors 282856-4 — Wire-to-Board Headers

TE Connectivity 282856-4 Buchanan Terminal Block, 4 Position

MPN282856-4
Active

TE Connectivity Buchanan 282856-4, 4-position PCB terminal block, 5.00 mm pitch, 24 A, 300 V, rising cage clamp, side entry, green housing, through-hole.

$1.9800Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesBuchanan
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

282856-4 key specifications
ParameterValue
SeriesBuchanan
MountingThrough Hole
Voltage300 V
Current24 A
Wire gauge12-30 AWG
Wire terminationScrew - Rising Cage Clamp
ColorGreen
Housing materialPolyamide (PA66), Nylon 6/6
Clamp material - platingBrass - Nickel Plated
Screw material - platingBrass - Nickel Plated
Contact material - platingBrass - Tin Plated
Pitch0.197\" (5.00mm)

All specifications

282856-4 additional specifications
ParameterValue
PackageBulk
FeaturesInterlocking (Side)
Screw threadM3
Torque - screw0.79 Nm (7.0 Lb-In)
Number of levels1
Mating orientationHorizontal with Board
Positions per level4

Product details

4-Position Buchanan Terminal Block for Power Distribution on the PCB

The 282856-4: The rising cage clamp — screw-driven with a brass-nickel-plated clamp and M3 screw torqued to 0.79 Nm — accepts wire from 12 AWG down to 30 AWG, so the same block handles both the main feed and smaller control wires. The green polyamide (PA66) housing is a visual cue common on Buchanan blocks, making it easy to spot on a crowded board.

Side-Entry Orientation and Interlocking for Ganged Assemblies

The interlocking side feature lets you snap multiple 282856-4 blocks together side-by-side without extra brackets, building a multi-position strip from single-position or multi-position modules. The 4-position block covers the common count for a three-phase plus neutral feed or a pair of DC rails.

Frequently asked questions

Is the 282856-4 suitable for 12 AWG wire?

Yes, the wire gauge range is 12-30 AWG, so 12 AWG stranded or solid fits the rising cage clamp. The M3 screw torque spec of 0.79 Nm (7.0 Lb-In) is the recommended setting to get full pull-out force without damaging the conductor.

Is 282856-4 RoHS compliant?

Yes, it is ROHS3 compliant per the listing, so it meets the current EU RoHS directive without exemptions.

Where can I buy 282856-4?

Sourced to order against your BOM quantity. Availability and pricing confirmed at quote time.
