TE Connectivity AMP Connectors Buchanan series, 282959-4, Plug, Female Sockets, 4 positions, 0.295" (7.50mm) pitch, 15 A, 300 V, screw - rising cage clamp, free hanging, green housing, UL94 V-0.
| Parameter | Value |
|---|---|
| Type | Plug, Female Sockets |
| Series | Buchanan |
| Mounting | Free Hanging (In-Line) |
| Voltage - UL | 300 V |
| Current - UL | 15 A |
| Plug wire entry | 180° |
| Wire strip length | 6-7.5mm |
| Wire gauge or range - AWG | 12-30 AWG |
| Wire gauge or range - mm2 | 0.05-2mm² |
| Operating temperature | -40°C ~ 110°C |
| Color | Green |
| Contact material | Phosphor Bronze |
| Parameter | Value |
|---|---|
| Housing material | Polyamide (PA66), Nylon 6/6 |
| Insulation height | 0.610\" (15.49mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.295\" (7.50mm) |
| Package | Bulk |
| Features | Retention Latches (Non-Wire Side) |
| Screw size | M3 |
| Torque - screw | 0.79 Nm (7.0 Lb-In) |
| Number of levels | 1 |
| Termination style | Screw - Rising Cage Clamp |
| Positions | 4 |
| Positions per level | 4 |
| Contact mating finish | Tin |
The 282959-4: Wire strip length is 6-7.5mm; the screw torque spec is 0.79 Nm (7.0 Lb-In). The M3 screw drives a rising cage clamp that lifts against the conductor – overtightening risks thread damage, so set the driver to the listed torque.
The pitch is 0.295" (7.50mm).
Yes, it is ROHS3 compliant.
Rated 15 A per circuit at 300 V per UL.
Torque is 0.79 Nm (7.0 Lb-In).
Accepts 12-30 AWG (0.05-2 mm²) solid or stranded wire.
