TE Connectivity AMP Connectors Buchanan series, 284514-4, Header, Male Pins, Shrouded (4 Side), 4 positions, 0.138" (3.50mm) pitch, through hole, vertical, 11 A, 300 V, green, bulk.
| Parameter | Value |
|---|---|
| Type | Header, Male Pins, Shrouded (4 Side) |
| Series | Buchanan |
| Mounting | Through Hole |
| Voltage - UL | 300 V |
| Current - UL | 11 A |
| Operating temperature | -40°C ~ 110°C |
| Color | Green |
| Contact material | Phosphor Bronze |
| Housing material | Polyamide (PA66), Nylon 6/6 |
| Insulation height | 0.362\" (9.20mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.138\" (3.50mm) |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Number of levels | 1 |
| Termination style | Solder |
| Header orientation | Vertical |
| Positions | 4 |
| Positions per level | 4 |
| Contact mating finish | Tin |
The 284514-4 is a 4-position, single-level, shrouded header from the Buchanan series, rated 11 A at 300 V. The 3.50 mm pitch and vertical through-hole orientation suit it for PCB-mounted terminal block applications where the mating plug inserts straight down.
284514-4 is an active TE Connectivity AMP Connectors part. We source it per RFQ — submit your quantity and target price for a current quote and lead time.
It is a 4-position header on 0.138" (3.50 mm) pitch, single level, vertical orientation.
