9-Position D-Sub Receptacle with Board Lock and 4-40 Screwlock
It carries gold-plated phosphor bronze signal contacts rated 6A per contact — the current limit is set by the pin density at the board edge, not the contact itself.
Mating Half and Field-Service Fit
This receptacle mates with a standard E shell size D-sub plug — the 4-40 female screwlock on the receptacle side accepts a male screwlock or jack-screw on the plug. The gold-plated contacts are rated for repeated mating cycles, making this a practical choice for field-serviceable connections where the cable is disconnected periodically. The board lock keeps the receptacle fixed to the PCB during connector mating and unmating, reducing stress on the solder joints.
