3-641435-6 — TE Connectivity AMP Connectors product photo

TE MTA-156 3-641435-6, 6-Pos IDC Plug, 0.156" Pitch

MPN3-641435-6
Active

TE Connectivity MTA-156 IDC plug, 3-641435-6, 6 positions, 1 row, 0.156" (3.96 mm) pitch, tin contacts, 18 AWG, free-hanging right-angle mount, closed end, bulk.

$1.2800Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

3-641435-6 Technical Specifications
ParameterValue
SeriesMTA-156
Wire typeDiscrete or Ribbon Cable
GenderMale Pin
Mounting typeFree Hanging (In-Line), Right Angle
Connector typePlug
Wire gauge18 AWG
Cable terminationIDC
ColorOrange
Pitch0.156\" (3.96mm)
PackageBulk
FeaturesClosed End
Contact finishTin
Rows1
Positions6
Contact finish thickness80.0µin (2.03µm)

Product details

The TE Connectivity 3-641435-6 is a 6-position IDC plug from the MTA-156 series, terminated to 18 AWG discrete or ribbon cable. Tin contacts at 80.0 µin (2.03 µm) thickness handle the mechanical and electrical duty for a fixed installation where the connector mates once and stays mated; the closed-end housing prevents a terminal from being pushed past the last cavity, which is a simple polarity check during harness assembly.

No wire stripping or crimping; the tooling is a simple press. The plug mounts free-hanging (in-line) or at a right angle, which suits a harness that exits a panel edge or a board-mounted header at 90°. Mates with the matching MTA-156 header (through-hole or surface-mount, straight or right-angle) — the 0.156" pitch and single-row layout are consistent across the series.

Frequently asked questions

Is 3-641435-6 RoHS compliant?

Yes, 3-641435-6 is RoHS compliant.
