It mates with standard 0.100" (2.54mm) pitch MTA-100 headers, and the locking ramp provides a positive, vibration-resistant latch. The closed-end design prevents wire over-insertion and protects the IDC slots from contamination.
Termination and Wire Prep — IDC on 26 AWG
This receptacle terminates 26 AWG wire via insulation displacement — no stripping required. The IDC slot cuts through the insulation and grips the conductor in one press operation. The housing accepts discrete wires or ribbon cable, and the closed end acts as a wire stop, ensuring consistent insertion depth across all six positions.
That's a heavy tin layer — good for moderate mating cycles in clean, dry environments.
Mounting and Orientation — Free-Hanging Right-Angle
Free-hanging (in-line) mounting with a right-angle cable exit.
