TE Connectivity AMP Connectors 3-647002-3 — Panel-Mount & In-Line Circular

TE MTA-100 3-647002-3, 3-Pos IDC Plug, 0.100" Pitch

MPN3-647002-3
Active

TE Connectivity MTA-100 IDC plug, 3 positions, 0.100" (2.54mm) pitch, 1 row, tin-plated contacts, 26 AWG, free-hanging right-angle, closed end, bulk.

$0.6200Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMTA-100
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

3-647002-3 specifications
ParameterValue
SeriesMTA-100
Wire typeDiscrete or Ribbon Cable
TypeMale Pin
MountingFree Hanging (In-Line), Right Angle
Connector typePlug
Fastening typeLatch Holder
Wire gauge26 AWG
Cable terminationIDC
ColorBlue
Pitch0.100\" (2.54mm)
PackageBulk
FeaturesClosed End
Contact finishTin
Rows1
Positions3
Contact finish thickness80.0µin (2.03µm)

Product details

0.100" Pitch, 3-Position IDC Plug for 26 AWG

The TE Connectivity 3-647002-3 is a 3-position IDC plug from the MTA-100 series, built for mass-terminating 26 AWG discrete or ribbon cable without stripping or crimping. The tin-plated contacts carry an 80.0µin (2.03µm) finish — thick enough for a solid gas-tight connection in a one-time or limited-cycle harness, but not meant for frequent reconnection. The closed-end design means this plug terminates the end of a cable run; there is no pass-through for daisy-chaining.

This plug is a free-hanging (in-line) right-angle IDC connector.

Frequently asked questions

Is 3-647002-3 RoHS compliant?

Yes, the 3-647002-3 is ROHS3 compliant per the manufacturer's listing.

Can 3-647002-3 be used with 26 AWG discrete wire?

Yes, the 3-647002-3 is rated for 26 AWG discrete or ribbon cable, terminated via IDC.

What is the pitch of the 3-647002-3 connector?

The pitch is 0.100" (2.54mm), standard for the MTA-100 series.
