TE PIDG 320773 Ring Terminal, #2 Stud, 16-22 AWG

MPN 320773
Active

TE Connectivity AMP Connectors PIDG ring terminal, order code 320773, #2 stud size, 16-22 AWG, red insulated, tin-plated copper, 0.031" (0.79mm) thickness, serrated termination, free hanging (in-line) crimp.

$0.5500 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSRoHS Compliant
IncotermsDAP / DDP Available
SeriesPIDG
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

320773 specifications
ParameterValue
SeriesPIDG
MountingFree Hanging (In-Line)
Terminal typeCircular
Wire gauge16-22 AWG
ColorRed
Contact materialCopper
Width - outer edges0.182\" (4.62mm)
Material - insulationPolyamide (PA), Nylon
PackageBulk
FeaturesSerrated Termination
Thickness0.031\" (0.79mm)
InsulationInsulated
TerminationCrimp
Stud (Tab size)2 Stud
Contact finishTin
Length - overall0.669\" (16.99mm)
Insulation diameter0.105\" ~ 0.140\" (2.67mm ~ 3.56mm)

Product details

PIDG ring terminal, #2 stud

The 320773 is the #2-stud member of TE's PIDG ring terminal line, accepting 16-22 AWG wire with a red polyamide insulation sleeve. The tin-plated copper contact is 0.031" (0.79mm) thick with a serrated crimp barrel that grips the conductor strands. Overall length is 0.669" (16.99mm); the insulation diameter range is 0.105" to 0.140" (2.67mm to 3.56mm).

Stud-size selection across the PIDG 16-22 AWG family

The 320773's #2 stud sits at the small end of the PIDG 16-22 AWG red ring terminal series. The 324158 shares the same #2 stud and overall dimensions but accepts a narrower insulation range of 0.080" to 0.125" (2.03mm to 3.18mm). For larger studs, the 323758 (#4) and 320554 (#8) offer wider outer edges and longer overall lengths — 0.250" (6.35mm) and 0.281" (7.14mm) respectively — while keeping the same 0.031" (0.79mm) thickness and tin-plated copper contact.
