TE Connectivity AMP Plasti-Grip ring terminal, order code 34152, 16-22 AWG, #3/8 stud, circular, tin-plated copper contact, serrated crimp, PVC insulated, free-hanging in-line, bulk.
| Parameter | Value |
|---|---|
| Series | Plasti-Grip |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Circular |
| Wire gauge | 16-22 AWG |
| Color | Red |
| Contact material | Copper |
| Width - outer edges | 0.531\" (13.49mm) |
| Material - insulation | Poly-Vinyl Chloride (PVC) |
| Package | Bulk |
| Features | Serrated Termination |
| Thickness | 0.031\" (0.79mm) |
| Insulation | Insulated |
| Termination | Crimp |
| Stud (Tab size) | 3/8 Stud |
| Contact finish | Tin |
| Length - overall | 1.230\" (31.24mm) |
| Insulation diameter | 0.105\" ~ 0.140\" (2.67mm ~ 3.56mm) |
The 34152 is the #3/8-stud member of TE Connectivity AMP's Plasti-Grip ring terminal line, accepting 16-22 AWG wire with a tin-plated copper contact and serrated crimp. PVC insulation covers the crimp barrel and a portion of the wire, with an insulation diameter range of 0.105" to 0.140" (2.67mm to 3.56mm).
The 34152 is RoHS Compliant per TE Connectivity AMP Connectors documentation.
