TE Connectivity AMP Connectors spade terminal, order code 41473, 14-18 AWG, #8 stud, non-insulated, tin-plated brass, crimp termination, free hanging (in-line), 0.542" overall length.
| Parameter | Value |
|---|---|
| Mounting | Free Hanging (In-Line) |
| Terminal type | Standard |
| Wire gauge | 14-18 AWG |
| Contact material | Brass |
| Width - outer edges | 0.275\" (6.99mm) |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Insulation | Non-Insulated |
| Termination | Crimp |
| Stud (Tab size) | 8 Stud |
| Contact finish | Tin |
| Length - overall | 0.542\" (13.77mm) |
| Length - termination | 0.120\" (3.05mm) |
| Tongue inside opening | 0.171\" (4.34mm) |
| Length - ring center to termination | 0.175\" (4.45mm) |
The 41473: The tin-plated brass body measures 0.542" overall length with a 0.171" tongue opening. Crimp termination suits free-hanging in-line installation; the 0.275" outer edge width fits standard barrier-strip spacing.
The 41473 accepts 14-18 AWG wire and fits a #8 stud. The tongue inside opening measures 0.171" (4.34 mm).
The 41473 is ROHS3 compliant per the manufacturer. No UL or IEC ratings are listed in the available documentation.
