TE Connectivity AMP Connectors ring terminal, order code 42673-2, 8-10 AWG, #10 stud, 0.040" (1.02mm) tab thickness, tin-plated brass, non-insulated, single stud hole, crimp termination, free hanging (in-line).
| Parameter | Value |
|---|---|
| Mounting | Free Hanging (In-Line) |
| Terminal type | Ring |
| Wire gauge | 8-10 AWG |
| Terminal style | Single Stud Hole |
| Contact material | Brass |
| Width - outer edges | 0.385\" (9.78mm) |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Insulation | Non-Insulated |
| Termination | Crimp |
| Stud (Tab size) | 10 Stud |
| Tab thickness | 0.040\" (1.02mm) |
| Contact finish | Tin |
| Length - overall | 0.717\" (18.21mm) |
| Diameter - ring ID | 0.197\" (5.00mm) |
The 42673-2 is a non-insulated ring terminal from TE Connectivity AMP Connectors, accepting 8-10 AWG wire and terminating to a #10 stud. The terminal is tin-plated brass with a single stud hole, a ring ID of 0.197" (5.00mm), and an outer edge width of 0.385" (9.78mm). Crimp termination is used for wire attachment; the terminal is designed for free-hanging (in-line) mounting. Tab thickness is 0.040" (1.02mm) and overall length is 0.717" (18.21mm).
