TE Connectivity AMP Connectors FFC/FPC housing, order code 487223-7, 26 positions, dual row, 0.100" (2.54mm) pitch, 300 V, 1.5 A, thermoplastic housing, locking ramp, bulk package.
| Parameter | Value |
|---|---|
| Connector type | Housing for Female Contacts |
| Flat flex type | FFC, Discrete Wire |
| Voltage rating | 300 V |
| Current rating | 1.5 A |
| Wire gauge | 22-32 AWG |
| Operating temperature | -65°C~105°C |
| Housing color | Black |
| Housing material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Note | Contacts Not Included |
| Pitch | 0.100\" (2.54mm) |
| Package | Bulk |
| Rows | 2 |
| Locking feature | Locking Ramp |
| FFC, FCB thickness | 0.05-0.13mm |
| Insulation diameter | 0.025\" ~ 0.056\" (0.64mm ~ 1.42mm) |
| Positions | 26 |
The 487223-7: Accepts 22-32 AWG discrete wire with an insulation diameter of 0.025" ~ 0.056" (0.64mm ~ 1.42mm) or FFC thickness 0.05-0.13mm. The locking ramp secures the housing to the mating header; contacts are ordered separately.
The 487223-7 is RoHS3 compliant. UL94 V-0 flammability rating is specified on the housing material.
