2-Position IDC Plug for Discrete Wire Harnesses
The TE Connectivity AMPMODU MTE 5-103945-1 is a 2-position male plug that terminates discrete 22-26 AWG wire via IDC — no crimp tool, no separate terminal. The insulation is displaced on insertion, making it a quick wire-to-board or in-line splice point for signal-level circuits. The 0.100" (2.54mm) pitch matches standard grid headers, so board layout is a drop-in with any 0.100" pin strip.
Position Count and Series Fit
At 2 positions this is the smallest member of the AMPMODU MTE IDC plug family. The same 0.100" pitch, single-row layout, gold 15.0µin contacts, and latch holder carry across the series, so the assembly process is identical whether you use the 2-position 5-103945-1 or the 3-position 5-103945-2, 4-position 5-103945-3, or 5-position 5-103945-4.
Termination and Housing Details
IDC termination accepts 22-26 AWG discrete wire — the slot width is fixed for that range, so wire outside it won't pierce or retain properly. Black housing in tube packaging; the base product number is 103945.
