10-Position IDC Receptacle on 0.100" Pitch
Accepts 22-26 AWG wire, single-row, 10 circuits, free-hanging mount. Black housing, shipped in tube.
IDC Termination — Ribbon or Discrete
This is an IDC connector, not a crimp-and-stuff. The cable termination is IDC, which means the wire is pressed into insulation-displacement slots in one operation — no stripping, no crimping, no individual terminal loading. It accepts either discrete wires or ribbon cable, so it works for both point-to-point harnesses and ribbon-bus assemblies. The 22-26 AWG range covers the common signal wire sizes for internal box wiring. The closed-end feature means the back of the housing is sealed — no exposed contact tails, no risk of shorting against a panel or another wire bundle.
The latch lock holds the pair mated until you squeeze the latch to release. Single-row, 10 positions, 0.100" pitch.
No last-time-buy or end-of-life notice on record.
