5-103959-4 — TE Connectivity AMP Connectors product photo
TE Connectivity AMP Connectors

TE AMPMODU MTE 5-103959-4, 5-Pos IDC Receptacle

MPN5-103959-4
Active

TE Connectivity AMPMODU MTE, Receptacle, 5 Positions, 0.100" (2.54mm) Pitch, 1 Row, IDC Termination, Tin Contact Finish, Free Hanging, Latch Lock, Closed End.

$2.4500Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

5-103959-4 Technical Specifications
ParameterValue
SeriesAMPMODU MTE
Wire typeDiscrete or Ribbon Cable
GenderFemale Socket
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeLatch Lock
Wire gauge26-30 AWG
Cable terminationIDC
ColorBlack
Pitch0.100\" (2.54mm)
PackageTube
FeaturesClosed End
Contact finishTin
Rows1
Positions5
Contact finish thickness100.0µin (2.54µm)

Product details

5-Position IDC Receptacle for Discrete or Ribbon Cable

The TE Connectivity AMPMODU MTE 5-103959-4 is a 5-position, single-row receptacle that terminates discrete or ribbon cable via IDC (Insulation Displacement Connection). Rated for 26-30 AWG wire, the IDC slot geometry is fixed at the factory — you don't adjust it for wire size. If the harness sees frequent reconnection or sits in a corrosive atmosphere, the tin plating will fret and oxidise faster than a gold-plated alternative.

Latch Lock and Free-Hanging Mount

For a free-hanging (in-line) receptacle, this is the primary retention mechanism — there's no board anchor or screw. The black housing is a visual key for the AMPMODU MTE system, but the latch orientation and keying are what prevent a mis-mate with a different position count.

It is RoHS compliant.

Frequently asked questions

Where can I buy 5-103959-4?

The 5-103959-4 is sourced to order through independent distribution. Submit an RFQ for current availability and pricing — stock and lead time are confirmed at quote time.

What is the mating connector for 5-103959-4?

Confirm the header's orientation (vertical or right-angle) and mounting style (through-hole or SMT) to match your board layout.

What wire gauge does 5-103959-4 support?

The IDC termination accepts 26-30 AWG discrete or ribbon cable. The slot geometry is fixed for this range — do not use wire outside these gauges, as the insulation displacement contacts will not pierce or grip correctly.
